Reactor, 500 Gallon, Glass Lined, 100 PSI, Jkt, Agit, 100 PSI #C732378
Reactor, 500 Gallon, Glass Lined, 100 PSI, Jkt, Agit, 100 PSI #C732378
Location:Chowchilla, CA
Available quantity:1
Description
Reactor, 500 gallon capacity, glass-lined, measures 48" diameter x 58" deep, dished top and bottom, 3" center bottom outlet, manufactured by Pfaudler, Model. RA48-500, glass-type 9115, rated for 100 PSI/full vacuum @ 450degrees /-20deg. F., jacket rated for 100 PSI @ 450 degrees / -20deg. F. Complete with glass-lined 3-blade retreat curve-type agitator with approx.10 HP drive thru Pfaudler 15.4:1 gearbox, 117 output RPM. Serial# R193-0096. Top inlets - (3) 2", (2) 3", 4" & 6" and 12" x 15" oval manway. Lug mounts and ports for legs. Good condition.
Specifications
| Stock Number | C732378 |
| Manufacturer | Pfaudler |
| Model | RA48-500 |
| Serial Number | R193-0096 |
| Gallons | 500 |
| Materials of Construction | Glass-Lined |
| Internal Pressure | 100 PSI / Full Vacuum @ 450/-20 deg. F |
| Jacket Pressure | 100 PSI @ 450/-20 deg. F |
| HP | 10 |
| Previous Use | Chemical Processing |
| Basis | FOB |
Additional Information
Drawings available upon request.
